Automatic Pillow Packaging Machine DXD-1200
Automatic Pillow Packaging Machine DXD-1200
Designed specifically for the confectionery industry, the DXD-1200 is ideal for packaging individual or multi-piece items. It ensures a professional aesthetic finish, superior seal integrity, and optimal hygiene, effectively extending shelf life. It is the preferred solution for large-scale confectionery production.
Feature
- Delivers high-speed output with superior accuracy, ensuring robust seals and enhanced hygiene to maximize product shelf life.
- Features a dual-spool design that supports non-stop film splicing, eliminating downtime and significantly boosting continuous production efficiency.
- Equipped with a sophisticated PLC system and variable frequency drive (VFD) technology for precise parameter management, adaptable to various packaging speeds and specifications.
- Features an industrial touchscreen interface with a visual menu system for clear, simplified parameter setup and reduced operator training requirements.
- Engineered for structural excellence, the machine offers smooth transmission and ultra-low noise operation, ensuring reliable, long-term stability for large-scale manufacturing.
| Model | DXD-1200 |
|---|---|
| Production Capacity | Up to 1,200 pieces/min |
| Max. Film Width | 120 mm |
| Max. Film Roll Diameter | 350 mm |
| Applicable Shapes | Square, Round, Oval, Rectangular, Cylindrical, Spherical |
| Product Dimensions | Length: 12–40 mm / Width: 12–30 mm / Height: 5–18 mm |
| Packaging Materials | Heat-sealable single/multi-layer films (OPP, CPP, PET, Metallized, Paper-Plastic, etc.) |
| Total Power | 4 kW |
| Power Supply | 220 V, 50 Hz |
| Dimensions (L×W×H) | Short Model: 2700 × 1350 × 1600 mm Extended Model: 3400 × 1350 × 1600 mm |
| Machine Weight | 1,300 – 1,600 kg |
